Chapter 3 121
Replacing the ODD Module
Replacing the Lower Covers
1. With the ODD tray in the eject position, replace the
ODD cover on the new ODD Module.
2. Turn the ODD over and replace the three securing
screws.
3. Slide Module in chassis and press until Module is
flush with chassis.
4. Replace the single securing screw as shown.
1. Replace the Memory Cover. 2. Replace the two securing screws to lock in place.
