CobraNet Programmer’s Reference
Management Interface Variable Reference
6.4.4 Errors
Name errorPOSTResults
Description
Power on self-test results. 0 - no errors detected. Currently the CobraNet interface does not recover
from a POST failure. This variable will always report 0. A POST failure is reported by the indicator
LED’s. A self-reset will be attempted following the error report.
Host Address
0x2000
SNMP Object ID
1.3.6.1.4.1.2680.1.1.3.1
Type
Integer
Attributes Read-only
Default Value 0
Implemented Version
2.1.0
Name
errorIndicators
Description
This value is a sum of exclusive binary values which can be OR’d to represent multiple errors.
0x01 - Fault
0x04 - Receive error
0x08 - Transmit error
0x10000 - Audio mute (audio output may be corrupt)
0x20000 - BuddyLink output disabled (fault or lost contact with the network)
0x40000 - Unexpected system error (diagnostic information on firmware fault may be available in
errorDisplay)
Host Address
0x2001
SNMP Object ID 1.3.6.1.4.1.2680.1.1.3.2
Type Integer
Attributes
Read-only
Implemented Version
2.1.0
Name
errorCode
Description
Last error code reported. On 24-bit platforms, error code is a byte in MS byte position of this
variable. On 32-bit platforms, error code is a byte in LS byte position of this variable. Some values
are warnings and will not affect
errorIndicators. See error table.
Note: this variable has also been referred to as errorLast in older documentation and MIB files.
Host Address
0x2002
SNMP Object ID
1.3.6.1.4.1.2680.1.1.3.3
Type Integer
Attributes Read-only
Default Value
0
Implemented Version
2.1.0
