CobraNet Programmer’s Reference
Management Interface Variable Reference
Name serialTxPriority
Description
Serial bridging bundle priority in MS byte. Higher priority bundles are transmitted earlier in the
isochronous cycle and are thus less susceptible to dropouts in the event network bandwidth is
exhausted. Request priority in LS byte. Contention for transmission on a bundle is resolved via
request priority.
This variable has no effect when
serialTxBundle is 0.
The reference design, CM-1,CM-2, CS4961xx, and CS1810xx-based designs do not support
isochronous transmission of serial data and ignore settings for serialTXBundle and serialTxPriority.
Host Address
0x24006
SNMP Object ID
1.3.6.1.4.1.2680.1.1.10.1.5
Type Integer16
Attributes Read/write - Persistent
Default Value
0x0110
Implemented Version
2.4.7 (available via SNMP in 2.6.4)
Name
serialTxBundle
Description
On legacy repeater Ethernet networks and CobraNet interface hardware, serialTXBundle is used to
specify a bundle number for use in transmitting serial data reliably over CobraNet's isochronous
audio transport service. Specifying bundle 0 causes serial data to be delivered normally via the
asynchronous transport. This is the default and recommended setting.
The reference design, CM-1,CM-2, CS4961xx- and CS1810xx-based designs do not support
isochronous transmission of serial data and ignore settings for serialTXBundle and serialTxPriority.
Host Address
0x24007
SNMP Object ID
1.3.6.1.4.1.2680.1.1.10.1.6
Type
Integer16
Attributes
Read/write - Persistent
Default Value 0
Implemented Version
2.4.7 (available via SNMP in 2.6.4)
Name
serialTxMAC
Description
MAC address of the CobraNet interface to which serial data is sent. May be any multicast or unicast
address.
Host Address
0x24100
SNMP Object ID
1.3.6.1.4.1.2680.1.1.10.1.7
Type
PhysAddress
Attributes
Read/write - Persistent
Default Value 01:60:2B:FD:00:00
Implemented Version
2.4.7 (available via SNMP in 2.6.4)
