CobraNet Programmer’s Reference
Error Code Reference
Byte
Code
Flash
Code
Type Name Description
Expected
Conditions
Unexpected
Conditions
85 3,6,3
TX
ETHERTX_CRS
Ethernet carrier
sense did not
assert in response
to transmission.
May be reported if
transmission is in
progress when
Ethernet is
disconnected.
-
86 5,6,3 TXQUIET
ETHERTX_LATECOLL
Late collision
occurred during
transmission.
Late collisions can
occur on a repeater
network if network
diameter exceeds
200 meters.
CobraNet's
collision avoidance
mechanism for
repeaters allows
network diameters
up to 2 kilometers.
On such networks,
late collisions are
expected in
transmission of
control data. The
collision detection
mechanism of a
device on the
network is
inoperative or a
device is
mistakenly
manually
configured for full-
duplex operation
on a repeater
network.
-
87 7,6,3
RXQUIET ETHERRX_SHORTPACKET
Received an
illegally short
Ethernet packet.
Collisions are
occurring on the
network.
A transmitter on
the network is
misbehaving.
Problem with
Ethernet controller.
88 1,7,3
TX
SCI_RXOVER
Asynchronous
serial receive
overrrun error.
Bad serial baud
rate selected.
-
89 3,7,3
TX
ETHERTX_LOSS_CARRIER
Loss of carrier
during Ethernet
frame
transmission.
Transmission in
progress when
Ethernet was
disconnected.
-
90 5,7,3
TX
SCI_RXFRAMING
Asynchronous
serial receive
framing error.
Wrong serial data
format or baud rate
selected.
-
91 7,7,3
RX
ETHERRX_LATECOLL
Late collision
detected during
reception.
Late collisions can
occur on a repeater
network if network
diameter exceeds
200 meters.
-
