96
©
Copyright 2006 Cirrus Logic, Inc. DS651PM25
CobraNet Programmer’s Reference
Management Interface Variable Reference
Name audioMeterRaw
Description
Efficiently retrieves all audioMeters values in a single Get operation. On 24-bit platforms,
audioMeterPeakRaw and audioMeterRaw values are packed in 3 octet words. On CS4961xx- and
CS1810xx-based platforms the values are packed in 4 octet words. Byte ordering for 24-bit is MS,
Middle, LS. Byte ordering for 32-bit platforms is MS, Middle High, Middle Low, LS.
Host Address
0x32000
SNMP Object ID 1.3.6.1.4.1.2680.1.1.5.2.1.6
Count
64
Type
Integer
Attributes
Read/write
Default Value
0
Implemented Version 2.9.3 (24-bit platforms), 2.10.4 (32-bit paltforms)
Name audioLoopSrc
Description
Describes source audio routing channels for performing a local audio loopback function. The first
unassigned (null or unconnected routing channel) loopback entry terminates loopback processing.
It is not possible to activate loopback element 3 without first activating loopback 2, for instance.
Host Address
0x34000
SNMP Object ID
1.3.6.1.4.1.2680.1.1.5.3.1.2
Count
8 in standard firmware build.
Type
Integer
Attributes
Read/write - Persistent
Default Value 0
Implemented Version
2.1.0
