CobraNet Programmer’s Reference
Error Code Reference
Byte
Code
Flash
Code
Type Name Description
Expected
Conditions
Unexpected
Conditions
104 1,3,4 FATAL
MODE_ASSERTFAIL
Programmer
assertion failed in
mi.a
- -
105 3,3,4
RX
ETHERRX_WATCHDOG_TIME
OUT
Receive watchdog
time-out.
Packet length
greater than 2048
bytes detected.
Signal integrity
problem in
Ethernet receive
circuitry.
106 5,3,4 FATAL
UNUSED
-
-
-
108 1,4,4 FATAL
UNUSED
-
-
-
110 5,4,4 FATAL
UNUSED
-
-
-
112 1,5,4 FATAL
UNUSED
-
-
-
114 5,5,4
RX
NO_BEAT_HEADER
Could not find
header section in
beat packet.
-
Conductor has
transmitted an ill
formed beat
packet.
115 7,5,4
RX
NO_ISO_HEADER
Could not find
header section in
isochronous data
packet.
Device has
transmitted an ill
formed
isochronous data
packet
-
116 1,6,4 FATAL
UNUSED
-
-
-
117 3,6,4
TX
BRIDGE_TX_SIZE
Packet bridge
transmission is too
big (>1514 bytes)
or too small (<14
bytes).
Host processor has
specified a size out
of range.
-
118 5,6,4 TXQUIET HMI_ADDRESS_INVALID
Invalid host MI
address specified.
Host processor lost
its mind or
assumes a different
MI version.
-
119 7,6,4 TXFAULT QUEUEPUT_TXCONTROL
Queue overflow
transmitting control
packets.
- -
120 1,7,4 FAULT
SSIPTR_SLIP
Unexpected audio
DMA pointer
location.
-
Problem with
audio DMA.
121 3,7,4
RX
SCIDATA_MISSING
Serial bridge
packet contained
no data section.
-
Malformed packet
transmitted by
another station or
packet was
truncated on
receipt.
122 5,7,4 FAULT
FRAME_FLOODED
Frame advance
processing not
completed before
beginning of next
frame.
- -
123 7,7,4
TX
ORDER_LOCKED
Transmit packets
not available at
transmission time.
Synchronization to
network scenario.
-
