82
©
Copyright 2006 Cirrus Logic, Inc. DS651PM25
CobraNet Programmer’s Reference
Management Interface Variable Reference
Name bridgeCalcMMACHash
Description
This variable is used to calculate a hash value based on the address in bridgeMMAC. Writing a
value different than bridgeMMACHashDone to this variable causes the calculation to begin. When
complete, bridgeMMACHashDone will be updated with the value written here and
bridgeMACHashBuf will contain the new hash value. Folding bridgeMACHashBuf resuls into
bridgeHashBuf will then allow receipt of packets from the multicast address specified in
bridgeMMAC.
Host Address 0x20005
SNMP Object ID
Not available via SNMP
Type
Integer
Attributes
Read/Write
Default Value
0
Implemented Version 2.2.0
Name
bridgeMMACHashBuffer
Description
This is the calculated hash value for the MAC address entered in bridgeMMAC.
Host Address
0x20006 - 0x20009
SNMP Object ID
Not available via SNMP
Size 4 words
Type
Octet String
Attributes
Read/Write
Default Value
0
Implemented Version
2.2.0
Name bridgeHashBuffer
Description
This is the value loaded to the hash table of the Ethernet controller which determines the range of
multicast addresses the host will receive.
Host Address
0x2000A - 0x2000D
SNMP Object ID
Not available via SNMP
Size 4 words
Type
Octet String
Attributes
Read/Write
Default Value
0
Implemented Version
2.2.0
