CobraNet Programmer’s Reference

Management Interface Variable Reference

DS651PM25

109

Name

txSubMap

Description

Transmit audio channel (channel within bundle) to audio routing channel (channel of SSI) mapping.
This vector contains the routing channel source specifiers per audio channel in the transmitted
bundle.

Host Address

0x5n20m (n is 0 based transmitter number, m is 0 based sub-channel number)

Count

SNMP Object ID

1.3.6.1.4.1.2680.1.1.7.2.1.2.n .m (n is 1 based transmitter number, m is 1 based audio channel)

Type

Integer

Attributes

Read/write - Persistent

Default Value

First transmitter {1, 2, 3, 4, 5, 6, 7, 8}
Second transmitter {9, 10, 11, 12, 13, 14, 15, 16}
Third transmitter {17, 18, 19, 20, 21, 22, 23, 24}
Fourth transmitter {25, 26, 27, 28, 29, 30, 31, 32}

Implemented Version

2.1.0

Name

txSubFormat

Description

Specifies data format for each sub-channel in the transmitted bundle. Please see

Table 6 on

page 23

for a complete list of valid format values.

modeRateControl must also be set correctly to

support the configured format.

Host Address

0x5n30m - 0x5n30m (n is 0 based transmitter number, m is 0 based sub-channel number)
