2.2.1.2. 24-bit HMI Packet Bridge Buffer Data Format
Packet byte length is specified in the two MS bytes of the first word. The LS bytes will read
0 on receipt and must be set to 0 for transmit. Transmit byte length is rounded up to the
nearest even multiple of 4. Receive byte length indicates the actual number of bytes
received.
2.2.1.3. 32-bit HMI Packet Bridge Buffer Data Format
Packet data begins with the second word. Transmission order of each word is MH, MS,
LS, ML.
Table 3. Packet Bridge Buffer Layout, 24-bit Platforms
MS
Middle
LS
Word 1
Packet byte length MS
Packet byte length LS
unused/0
Word 2
Destination MAC byte 2
Destination MAC byte 3
unused/0
Word 2
Destination MAC byte 4
Destination MAC byte 3
unused/0
Word 3
Destination MAC byte 6
Destination MAC byte 5
unused/0
Word 4
Source MAC byte 2
Source MAC byte 1
unused/0
Word 5
Source MAC byte 4
Source MAC byte 3
unused/0
Word 6
Source MAC byte 6
Source MAC byte 5
unused/0
Word 7
Protocol identifier LS
Protocol identifier MS
unused/0
Word 8
Payload byte 2
Payload byte 1
unused/0
...
...
...
unused/0
Word n
Payload byte n
Payload byte n-1
unused/0
Table 4. Packet Bridge Buffer Layout, 32-bit Platforms
MS
MH
ML
LS
Word 1
Byte length MS
Byte length LS
unused/0
unused/0
Word 2
Destination MAC byte 2
Destination MAC byte 1
Destination MAC byte 4
Destination MAC byte 3
Word 3
Destination MAC byte 6
Destination MAC byte 5
Source MAC byte 1
Source MAC byte 2
Word 4
Source MAC byte 4
Source MAC byte 3
Source MAC byte 6
Source MAC byte 5
Word 5
Protocol identifier LS
Protocol identifier MS
Payload byte 2
Payload byte 1
Word 6
Payload byte 4
Payload byte 3
Payload byte 6
Payload byte 5
...
...
...
...
...
Word n
Payload byte n-2
Payload byte n-3
Payload byte n
Payload byte n-1
