CobraNet Programmer’s Reference
Management Interface Variable Reference
DS651PM25
©
Copyright 2006 Cirrus Logic, Inc. 119
6.5 DSP Extensions
The CS4961xx family of CobraNet interface chips features a MIB extension for control
and monitoring of the digital signal processing capabilities.
6.5.1 Processor
The proc variables provide general control and monitoring of the digital signal processing.
Name
procMode
Description
Signal processing mode:
0 - Silent (default)
1 - Audio pass-thru
2 - Run User Configuration
Host Address
0x75100
SNMP Object ID
1.3.6.1.4.1.2680.1.4.1.1
Type
Integer
Attributes Read/write - Persistent
Implemented Version
2.11.0
Name
procStatus
Description
Processor status, the following values may be OR’ed together:
0x1 - Pass-thru
ox2 - Running user configuration
0x4 - Firmware mismatches the chip
0x8 - Firmware channel number mismatches the user's configuration
ox10 - Firmware version mismatches the DSP Conductor kernel version
0x20 - Invalid user configuration
Bits 2 to 31 are only valid when bit 1 is set.
Host Address
0x75200
SNMP Object ID
1.3.6.1.4.1.2680.1.4.1.2
Type Integer
Attributes
Read Only
Implemented Version
2.11.1
