CobraNet Programmer’s Reference
Management Interface Variable Reference
DS651PM25
©
Copyright 2006 Cirrus Logic, Inc. 105
6.4.12 Transmitters
Name txDropouts
Description
Count of times channel transmission has been interrupted. Interruptions can be caused by loss of
transmit permission from conductor or by changes to
txBundle. Implemented by counting transitions
to 0 of txPosition.
Host Address
0x5n000 (n is 0 based transmitter number)
SNMP Object ID
1.3.6.1.4.1.2680.1.1.7.1.1.7.n (n is 1 based transmitter number)
Type
Counter
Attributes Read-only
Default Value 0
Implemented Version
2.1.0
Name
txPosition
Description
Transmission permission position. 0 indicates no transmission either because the conductor has not
granted permission (due to bandwidth constraints or bundle conflict) or
txBundle is set to 0. Valid
values are 0 through the number of bundles active on the network. A value of 1 indicates the
transmitter has the highest priority on the network and will be the last to be dropped if bandwidth is
exhausted.
Host Address 0x5n001 (n is 0 based transmitter number)
SNMP Object ID 1.3.6.1.4.1.2680.1.1.7.1.1.8.n (n is 1 based transmitter number)
Type
Integer
Attributes
Read-only
Default Value
0
Implemented Version
2.1.0
Name
txReceivers
Description
Number of receivers requesting this bundle. This may not be valid for multicast bundles as receivers
of multicast bundles are not required to issue a reverse reservation although all receivers currently
do.
A transmitter will track no more than 4 receivers.
txReceivers will never exceed 4.
Host Address 0x5n002 (n is 0 based transmitter number)
SNMP Object ID
1.3.6.1.4.1.2680.1.1.7.1.1.9.n (n is 1 based transmitter number)
Type
Integer
Attributes
Read-only
Implemented Version
2.5.7
