Signal – Horner APG SmartStack I/O HE-DIQ716 User Manual
Page 3
MAN0268-09
10 NOV 2006
PAGE 3
DIQ716
Information is subject to change without notice. SmartStack is a trademark of Horner APG, LLC.
2.2 Output
Wiring
Signal
Pin
DIQ716 OUTPUT
C4 Common
Q1 Output
1
Q2 Output
2
Q3 Output
3
Q4 Output
4
V1
Load Power 1
C4 Common
Q5 Output
5
Q6 Output
6
Q7
Output 7
Q8 Output
8
V2
Load Power 2
C4 Common
Q9 Output
9
Q10
Output 10
Q11 Output
11
Q12 Output
12
V3 Load
Power
NC
No Connection
*
OCS Bottom View – Shows
Corresponding I/O Pin
Q1
Q2
Q3
Q4
Q9
Q10
Q11
Q12
Q5
Q6
Q7
Q8
V2
V3
NC
LOAD
LOAD
LOAD
LOAD
V1
C4
C4
C4
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
001DIQ011-R1
*
