PAGE 2 10 NOV 2006 MAN0234-09
ADC010-110
Information is subject to change without notice. SmartStack is a trademark of Horner APG, LLC.
.
2 WIRING
Signal
ADC110 ADC010
1+ Channel 1+ Channel 1+
1- Common Common
Shield Shield
2+ Channel 2+ Channel 2+
2- Common Common
Shield Shield
3+ Channel 3+
3- Common
Shield
4+ Channel 4+
4- Common
Shield
3 INTERNAL CIRCUIT SCHEMATIC
*
OCS Bottom View – Shows
Corresponding I/O Pin Location
I/O Connector
Gnd
Shield
To
Controller
1+
1-
SmartStack
Field
Side
1+
2+
3+
4+
1-
2-
3-
001ADC001-R1
INPUT
V
INPUT
V
INPUT
V
INPUT
V
INPUT
V
4-
*
