OCX003 19 MAR 2003 PAGE 1
Information is subject to change without notice. Cscape is a trademark of Horner APG, LLC.
1 SPECIFICATIONS
ANALOG
INPUT
Number of Channels
4
Analog Inputs
Input Points Required
4
Input Ranges
±10 VDC
±20 mA
Conversion Time
(PLC Update Rate)
Set by PLC Scan Time
Resolution 12-Bit Converter Type
Successive
Approximation
Input Impedance
±10 VDC 1 Megohm
±20 mA 100 Ohms ,
Clamped @ 12VDC,
35mA Max. Continuous
Additional error for
temperatures other than
25
°
C
0.01% /
°
C
Maximum Error at
25
°
C
0.1% Maximum Over-Current 35mA
DIGITAL INPUT
Inputs per Module 16 Input Characteristics Bidirectional
Isolated Commons
per Module
2 Input Impedance 10K Ohms
Input Voltage Range 12-24VDC
Minimum ON Current 1mA
Peak Voltage 35VDC Max. Maximum OFF Current 200
µ
A
Isolation
(Between isolated
commons and
Ground)
500VDC OFF to ON Response 1ms.
ON Voltage Level 9VDC
OFF Voltage Level 3VDC
Output Compliance
Voltage for ±20mA
±10 VDC
ON to OFF Response 1ms.
DIGITAL OUTPUT
Outputs per Module 16 Maximum Inrush Current 650mA
Load Power Circuits
per Module 1 Minimum Load None
Operating Voltage 10 - 30VDC OFF to ON Response 1ms.
Output Type Sourcing / 10K Pull-Down ON to OFF Response 1ms.
Peak Voltage 30VDC Max. Output Characteristics Current Sourcing
Maximum Load
Current per Output
0.5A Max. Output Protection Short Circuit
General Specifications
Required Power
(Steady State)
To Be Determined
Operating
Temperature
0
°
to 50
°
Celsius
Required Power (Inrush) To Be Determined Terminal Type Spring Clamp, Removable
Relative Humidity 5 to 95% Non-condens ing Weight 9.5 oz. (270 g)
MAN0556-02
24VDC Digital In
24VDC, 0.5A Sourcing Digital Out
±10V, ±20mA Analog In
HE500OCX003
Mini OCX/RCX
