MAN0543-03

05 MAR 2003

PAGE 5






















Figure 5 – Dimensions (OCS551)



2.4

OCS651 (12-inch)






















Figure 6 – Panel Cut-out (OCS651)

001OCS015

12.29 [312.0mm]

9.66 [245.4mm]

F7

F4

F3

F2

F1

SYSTEM

F5

F6

POWER

001OCS014

3.68

[93.5mm]

9.09

[230.9mm]

11.95 [303.5mm]
