Serial Communications
5
Wiring and Jumpers
Wire according to the type of inputs / outputs used, and select the appropriate
jumper option.
5.1.
Wiring Examples
J1 Orange
Terminal
Connector
XE102
Name
I1
IN1
I2
IN2
I3
IN3
I4
IN4
I5
IN5
I6
IN6
I7
IN7
I8
IN8
H1
HSC1 /IN9
0V
Ground
A1
ES2T-250/300
A2
ESP-100
A3
Analog IN3
A4
Analog IN4
0V
Ground
5.2.
I/O Jumpers Settings (JP1 - JP2)
5.3.
External DIP Switch Settings (or Jumpers Settings)
6
Derating
J2 Black
Terminal
Connector
XE102
Name
C6
Relay 6 COM
R6
Relay 6 NO
C5
Relay 5 COM
R5
Relay 5 NO
C4
Relay 4 COM
R4
Relay 4 NO
C3
Relay 3 COM
R3
Relay 3 NO
C2
Relay 2 COM
R2
Relay 2 NO
C1
Relay 1 COM
R1
Relay 1 NO
H4
HSC4 / IN12
H3
HSC3 / IN11
H2
HSC2 / IN10
Serial Communications:
MJ1: (RS-232 / RS-485) Use for Cscape programming and Application-
Defined Communications.
MJ2: (RS-232 / RS-485) Use for Application-Defined Communications.
Pin
MJ1 Pins
MJ2 Pins
Signal
Direction
Signal
Direction
8
TXD
OUT
TXD
OUT
7
RXD
IN
RXD
IN
6
0 V
Ground
0 V
Ground
5
NC
No
Connect
NC
No
Connect
4
RTS
OUT
TX-
OUT
3
CTS
IN
TX+
OUT
2
RX- /
TX-
IN / OUT
RX-
IN
1
RX+ /
TX+
IN / OUT
RX+
IN
1
8
001XLE015
0V ON J1
12-24VDC
R2
C2
R3
C3
R6
C6
R4
C4
R5
C5
R1
C1
H4
H2
H3
LOAD
230VAC
OR
25VDC
N
L
LOAD
230VAC
OR
25VDC
N
L
LOAD
230VAC
OR
25VDC
N
L
LOAD
230VAC
OR
25VDC
N
L
LOAD
230VAC
OR
25VDC
N
L
LOAD
230VAC
OR
25VDC
N
L
XE102 J2 Black
Positive Logic
Digital In / Relay Out
Location of I/O jumpers (JP)
and wiring connectors
(J1 and J2).
I1
0V
001XLE036
12-24VDC
I1
0V
Positive Logic In Negative Logic In
Positive Logic vs. Negative Logic Wiring
The XLE can be wired for Positive Logic inputs or Negative
Logic inputs.
Wiring Specifications
For I/O wiring (discrete), use the
following wire type or equivalent:
Belden 9918, 18 AWG or larger.
For shielded Analog I/O wiring,
use the following wire type or
equivalent: Belden 8441, 18
AWG or larger.
For
CAN
wiring,
use
the
following wire type or equivalent:
Belden 3084, 24 AWG or larger.
J1
JP2
JP1
J2
001XLE062
Note:
Loop Power requirements are determined
by the transmitter specification.
Note: The Cscape Module Setup configuration must match the selected I/O (JP) jumper settings.
001XLE026
JP1 Digital DC In / HSC
Positive Negative
Logic Logic
Default
JP2 Analog In (A3 – A4)
Current Voltage
(20 mA) (10 V)
Note:
When using JP2 (A3-A4),
e
ach channel can be
independently configured.
001XLE066
Some XLes have jumpers
to
set
RS-485
port
termination, though most
use DIP Switches.
The External Jumpers or
DIP Switches are used for
termination of the RS-485
ports. The XLE is shipped
un-terminated.
To terminate, select one
of the jumpers shipped
with the product and
insert it based upon the
option that is desired or,
select the switch and
configure based upon the
option that is desired.
Factory Use
(default – none)
MJ2 Termination
(default – none)
MJ1 Termination
(default – none)
001XLE037
As seen when looking at the top of the XLE unit: Refer to
Section 3 for the location of the External Jumpers.
001XLE037-R1
Factory Use
(default – none)
MJ2 Termination
(default – none)
MJ1 Termination
(default – none)
XLE102 Relay Life Expectancy
0
10
20
30
40
1
2
3
4
Contact Current (A)
O
p
e
ra
ti
o
n
(x
1
0
4
)
12-24VDC
I1
I2
I3
I4
0V
A1
A2
0V
I5
I6
I7
I8
A3
A4
H1
001XLE067
20mA LOOP
0-10VDC
P
T
XE102 J1 Orange
Positive Logic in
Digital In / Analog In
