40
When desired FS input value is displayed on screen for example
00110.00000
Press ENTER to accept
HHC will go back to Percent Error MENU and advance to the next
programmable parameter.
Use DOWN or UP ARROW to highlight “Output channel…”
Press ENTER
Use DOWN or UP ARROW to highlight “CH1” (Channel 1
Module) or “CH2” (Channel 2 module) or “External Input…”
Note: Typically external input is used with transducers that pro-
vide voltage or current output signals.
Press ENTER
HHC will go back to Percent Error MENU and advance to the next
programmable parameter..
Use DOWN or UP ARROW to highlight “Output range…”
Note: Typically this is the output range of the device under test.
For this example the unit under test has 0-6Vdc output.
Use DOWN or UP ARROW to highlight “4-20”, “0-X”, “1-X” or
“Custom”
If a range ending in “–X” or “Custom” is selected the operator can
program the numeric value for the variable as follows
Use DOWN or UP ARROW to highlight “0-X”
Output “0-X” screen will be displayed.
Use DOWN or UP ARROW to highlight “0-5” through “0-100”, if
desired value is not displayed select “Custom”
If a custom range is needed:
Select “Custom”
Press ENTER
Display shows “Input FS screen”
SECTION 15 h. PERCENT (%) ERROR FUNCTION
CONT.
Output Range
4-20
0-x
1-x
Custom
Output 0-x
0-5
0-10
0-60
0-100
Custom
