Use DOWN or UP ARROW to highlight 4-20, 0-X, 1-X or Custom
Note: If a range ending in “–X” or “Custom” is selected the operator
can program the numeric value for the variable as follows
If a custom range is required:
Use DOWN or UP ARROW to highlight “Custom”…
Note: programming of Custom and “X” values uses similar proce-
dures for setting numeric values and decimal positions.
Input Zero screen will be displayed.
Press left and RIGHT ARROWs to position cursor (^) beneath
desired numeric character.
Press UP and DOWN ARROWs to scroll numeric values.
When desired numeric value is displayed in proper decimal
position
Press left or RIGHT ARROW to move cursor beneath the next
digit to be programmed.
When desired Zero input value is displayed on screen for example
00010.00000
Press ENTER to accept
Input FS (Full Scale) screen will be displayed.
Press left and RIGHT ARROWs to position cursor beneath
desired numeric character.
Press UP and DOWN ARROWs to scroll numeric values.
When desired numeric value is displayed in proper decimal
position
Press left or RIGHT ARROW to move cursor beneath the next
digit to be programmed.
SECTION 15 h. PERCENT (%) ERROR FUNCTION
CONT. Input range
4-20
0-x
1-x
Custom
Input Zero
00001.00000
^
Enter to accept
Esc to cancel
Input FS
00006.00000
^
Enter to accept
Esc to cancel
