Program Channel Tag Names (up to 7 characters)
The default channel names, Channel 1, Channel 2 and Ext can
be re-programmed by the user.
Press MENU key
Use DOWN or UP ARROW to highlight Datalog…
Press ENTER
Use DOWN or UP ARROW to highlight Set channel tags……
Press ENTER
Use DOWN or UP ARROW to highlight Channel 1, Channel 2 or
external input…
Press ENTER
Display will show “Enter CH 1 Tag”
“^“ Beneath a character or space indicates which character in the
tag name is being configured.
Use the DOWN or UP ARROW to scroll through alpha and
numeric characters
Note: Pressing the DEL key will advance the alpha numeric char-
acter to the blank space character which is the divider between
numeric and lower case alpha characters.
Use the left and RIGHT ARROWs to move the cursor.
When tag name is displayed as desired press ENTER
Display will return to the “Select Channel” MENU
Choose another channel to program or press MENU to exit
to Measurement Mode or ESC to move back to the “Datalog
“MENU.
Program Auto Datalog Time
Auto Datalogging allows the user to program a Datalogging inter-
val between 0.1 second and 86,400 seconds (24 hours).
Press MENU key
Use DOWN or UP ARROW to highlight “Datalog…”
Press ENTER
Use DOWN or UP ARROW to highlight “Manual/Auto…”
Press ENTER
Use DOWN or UP ARROW to highlight Manual or Auto, select
“Auto”…
Press ENTER
Display will show “Set Log Interval”
SECTION 15 f. i. Program Channel Tag Names
Enter CH1 tag
Ch1
^
Enter to accept
Escape to cancel
Datalog
Manual/Auto
Review data
Set channel tags
Export to SD
Clear internal storage
SECTION 15 f. ii. Program Auto Datalog Time
