IntelliStripe 65 Command Reference
78
On a successful read:
Field MTYP APPL CMND RC
Byte 1 2 3 4
Value (Hex) 80 0E 00 00
Field DATA
Byte 5 – up to 124 (Variable Length)
Value (Hex) DF 23 (LEN) (Track 1 Data) DF 22 (LEN)
(Track 2 Data)
Contactless Magstripe Notification message for Mifare:
On a successful read:
Field MTYP APPL CMND RC
Byte 1 2 3 4
Value (Hex) 80 0E 00 00
Field DATA
Byte 5 – up to 124 (Variable Length)
Value (Hex) DF 0D (LEN) (UID)
Notes:
(1) DF 23 is the header for Track 1
(2) DF 22 is the header for Track 2
(3) LEN number of bytes available for Track 1 or Track 2.
(4) For Track 2 data, 2 characters are sent using one byte, the application software will have
to convert each character into two bytes.
(5) DF 0D id the header for a Mifare Card’s UID. See appendix D to read Mifare cards.
RF ON Command
Command ID: 84 (Hex)
Description:
This command is used to turn the RF field ON.
Request Message Data: None
Response Message Data: None
Response Message Result Codes:
Success = 00 (Hex)
The command completed successfully.
Example Request:
Field MTYP APPL CMND RC
Byte 1 2 3 4
Value (Hex) 00 0E 84 00
