Section 10. OTI SCI 1000 Contactless Smart Card Application
77
Example Set Property Request:
Field MTYP APPL CMND RC PTYP PID
Byte 1 2 3 4 5 6
Value (Hex) 00 0E 01 00 03 01
Field PVAL
Byte 7
Value (Hex) 01 (AUTOMATIC RF CONTROL - ON)
Example Set Property Response:
Field MTYP APPL CMND RC
Byte 1 2 3 4
Value (Hex) 40 0E 01 00
Example Get Property Request:
Field MTYP APPL CMND RC PTYP PID
Byte 1 2 3 4 5 6
Value (Hex) 00 0E 00 00 03 01
Example Get Property Response:
Field MTYP APPL CMND RC PTYP PID
Byte 1 2 3 4 5 6
Value (Hex) 40 0E 00 00 03 01
Field PVAL
Byte 7
Value (Hex) 01 (AUTOMATIC RF CONTROL – ON)
Auto Mode
The contactless module is always in Auto Mode and will automatically read the card’s equivalent
magnetic stripe data when it comes within reading range. The reader will also sound a buzzer
when the contactless card data is successfully read. This data is also sent to the host
automatically.
Example Notification Sequence
On the assumption that the Notify Contactless Magstripe Property is ON, the application
will send the message when a contactless card comes into the operating field.
Contactless Magstripe Notification message for Paypass, Visa Wave, ExpressPay and
Discover:
