IntelliStripe 65 Command Reference
48
Example Request:
Field MTYP APPL CMND RC DATA
Byte 1 2 3 4 5-11
Value (Hex) 00 02 85 00 00 A4 02 0C 02 00 01
Example Response:
Field MTYP APPL CMND RC DATA
Byte 1 2 3 4 5-6
Value (Hex) 40 02 85 00 90 00
SELECT CONNECTOR COMMAND
Command ID: 86 (Hex)
Description:
The IFD supports up to 8 connectors numbered 0-7. Connector 0 is the User Connector, and is
used by default when the system starts. Connectors 1-7 may be used for Secure Access Modules
(SAMs) as part of application infrastructure.
This command allows the application to select the connector to be used in commands that follow.
The connector assignment stays in effect until it is changed by another Select Connector
Command or the device is power cycled.
Request Message Data:
Byte Field Description
1 Connector Number The number, in Hex, to be selected
Response Message Data: None
Response Message Result Codes
Code Meaning
00 Success
Example Request:
Field MTYP APPL CMND RC DATA
Byte 1 2 3 4 5
Value (Hex) 00 02 86 00 02
Example Response:
Field MTYP APPL CMND RC
Byte 1 2 3 4
Value (Hex) 40 02 86 00
