IntelliStripe 65 Command Reference
110
OpCode
AB
Name: Decrement
Description: Decrement value of block in RAM
Data structure: Op Code (one byte), Block # (one byte), Value (4 bytes)
Data Response structure: Op Code (one byte)
AC
Name: Transfer
Description: Move RAM value to EE
Data structure: Op Code (one byte), Block # (one byte)
Data Response structure: Op Code (one byte)
AD
Name: HALTA
Description: ISO 14443-3 Type A HALTA command in short frame.
Data structure: Op Code (one byte)
Data Response structure: Op Code (one byte)
AE
Name: Restore
Description: Restore recent value of block
Data structure: Op Code (one byte), Block # (one byte)
Data Response structure: Op Code (one byte)
AF
Name: Decrement & Transfer
Description: Implement the Decrement & Transfer functions together
Data structure: Op Code (one byte), Block # (one byte), Value (4 bytes)
Data Response structure: Op Code (one byte)
B0
Name: Authentication2
Description: Authentication versus a PICC
Data structure: Op Code (one byte), Mode (one byte), Key # (one byte), Sector
# (one byte)
Data Response structure: Op Code (one byte)
C0
Name: Read Macro
Description: Enables Read operation of Multiple Blocks of one Sector
Data structure:
Op Code (one byte),
Address (one byte) Bits 0-3 for Sector Number,
Bits 4-7 for Block Mask (Bit 4 for Block 0 up to Bit 7 for Block
3)
Auth2KeySel (one byte) 0 – Use Key A
1 – Use Key B
Data Response structure:
Op Code (one byte)
Data Sequential Data of all requested Blocks, from Lowest to Highest - Each
Block 16 bytes length.
