Page 81
75
SECTION 10. OTI SCI 1000 CONTACTLESS SMART CARD
APPLICATION
Application ID: 0E (Hex)
Description:
This application deals with communications with the OTI module. This module supports
MasterCard-PayPass™, Visa-Wave™ , AMEX-ExpressPay™, Discover and Mifare cards.
GET/SET/SAVE PROPERTY COMMANDS
Get Property Command ID: 00 (Hex)
Set Property Command ID: 01 (Hex)
Save Property Command ID: 02 (Hex)
Description:
These commands are used to retrieve and set the value of application properties. Details of these
commands are described in the Generic Command Section of this document. The following
describes each property this application supports.
NOTIFY CONTACTLESS MAGSTRIPE PROPERTY
Property ID: 00 (Hex)
Property Type: Boolean
Power Up/Reset Value: 1 (ON)
Get/Set support: Both
Description:
If the Notify Contactless Magstripe state is set to ON, then a notification message will be sent to
the host when a Contactless Smart Card enters the operating field.
Values:
Value
Notify Answer To Request State
0
OFF
1
ON
Example Set Property Request:
Field
MTYP
APPL
CMND
RC
PTYP
PID
Byte
1
2
3
4
5
6
Value (Hex)
00
0E
01
00
03
00
Field
PVAL
Byte
7
Value (Hex)
01 (NOTIFY ANSWER TO REQUEST STATE - ON)
