15
SECTION 4. MAGNETIC STRIPE APPLICATION
Application ID: 01 (Hex)
Description:
This application deals with decoding and presenting magnetic stripe card data. This application
works closely with the transport application, which deals with card transportation and magnetic
stripe data acquisition. The transport application must be used to acquire magnetic stripe data
before any data is available to decode and present by the magnetic stripe application.
GET/SET/SAVE PROPERTY COMMANDS
Get Property Command ID: 00 (Hex)
Set Property Command ID: 01 (Hex)
Save Property Command ID: 02 (Hex)
Description:
These commands are used to get, set and save the value of application properties. Details of
these commands are described in the Generic command section of this document. The following
describes each property this application supports.
NOTIFY READ STATE PROPERTY
Property ID: 00 (Hex)
Property Type: Dword
Power Up/Reset Value: 0 (OFF)
Get/Set/Save support: All
Description:
If the notify read state is not set to OFF, then a notification message will be sent to the host when
a card is read. The notification message will have the same syntax as the command response of
the command that corresponds to the Notify Read State. The only difference is that the message
header will contain a notification message type instead of a response message type. Note that
when the Notify Read State is set to GET TRACK DECODE DATA, the track number is
obtained from the Notify Read Track Property.
Values:
Value Notify Read State
0 OFF
1 GET TRACK 123 DECODE DATA
2 GET TRACK DECODE DATA
