Section 5. Smart Card Application
43
T=1 ERROR / WARNING CONDITION TEMPLATES
Byte Bit Meaning
0 0 Timeout On Receive. This condition indicates a receive timeout.
0 1 Parity Error in received data. This condition indicates that there was
a parity error in a message received from the card.
0 2 I/O errors in a message received from the card. These errors could
be Length, EDC, or an invalid PCB.
0 3 The card rejected a message with the indication: Error Free
0 4 The card rejected a message with the indication: EDC Error
0 5 The card rejected a message with the indication: Other Error
0 6 Reserved for Future Use.
0 7 Card Aborted a chain being sent by the IFD.
1 0 Card Aborted a chain being sent by the Card.
1 1 Input Buffer Overflow. The card tried to send a chain of messages
that is larger than the available buffer space.
1 2 The card sent an I-Block message (or chain) with no content in the
INF field.
1 3 The card was sending chained data when a Resynch sequence was
required; the chained data from the card was lost.
1 4 The IFD was not sending a chained message to the card and the
card sent an R-Block requesting a message other than the one we
are trying to send. This is a protocol error on the part of the card.
1 5 Invalid Sequence Number in an I-Block received from a card.
1 6 The IFD was sending a chained message to the card and the card
sent an R-Block requesting a message other than the one we are
trying to send.
1 7 Reserved for Future Use
2 0 Invalid S-Block Response Type from the card. An S-Block was sent
to the card and it responded with an S-Block of the wrong type.
2 1 Invalid S-Block Response Data from the card. An S-Block was sent
to the card and it responded with an S-Block with an invalid INF field.
2 2 Invalid S-Block Request Type from card. The card sent an S-Block
Request with an invalid Type.
2 3 Invalid S-Block Request Data from card. The card sent an S-Block
Request with an invalid INF field.
2 4 Resynch needed, completed successfully.
2 5 Resynch needed, but not performed because it is disables (property
Initial Resynch Allowed or Current Session Resynch Allowed).
2 6 Resynch not attempted, protocol had not yet started.
2 7 Reserved for Future Use
3 0 Resynch failed.
3 1 S-Block exchange failed, no more retries.
3 2-7 Reserved for Future Use
