DME HYDRAULIC LOCKING CORE PULL CYLINDERS Specification No. ME-E32-0001(C)
Part No. HLCP-PS01 Page 3 of 12
MOLD DESIGN CONSIDERATIONS (continued):
TABLE 1.3 — MASSES AND THREAD SIZES
Assembly Number
Mass
Thread Size
in Piston Rod
Thread Tap Hole Depth
to Drill Point
kg lb
HLCP060-1000 1.8 3.97
5/16 - 24 UNF 20mm
HLCP060-2000 2.0 4.41
HLCP100-1250 2.9 6.39
5/16 - 24 UNF 20mm
HLCP100-2500 3.2 7.05
HLCP150-1375 5.0 11.02
3/8 - 24 UNF 28mm
HLCP150-2750 5.4 11.90
HLCP200-1750 9.3 20.50
1/2 - 20 UNF 35mm
HLCP200-3500 10.5 23.15
HLCP300-2000 20.1 44.31
5/8 - 18 UNF 40mm
HLCP300-4000 22.4 49.38
HLCP500-2500 31.0 68.34
5/8 - 18 UNF 42mm
HLCP500-5000 33.0 72.75
HLCP750-3000 55.5 122.36
3/4 - 16 UNF 50mm
HLCP750-6000 62.1 136.91
