DME HYDRAULIC LOCKING CORE PULL CYLINDERS Specification No. ME-E32-0001(C)
Part No. HLCP-PS01 Page 10 of 12
HYDRAULIC LOCKING CORE PULL CYLINDER ASSEMBLY — BILL OF MATERIALS
TABLE 4.6: HLCP200-1750 TABLE 4.7: HLCP200-3500
ITEM NO. PART NO. DESCRIPTION QTY. ITEM NO. PART NO. DESCRIPTION QTY.
1 HLCP200BODY HLCP CYLINDER, BODY 1 1 HLCP200BODY HLCP CYLINDER, BODY 1
2 HLCP2001750SL HLCP CYLINDER, SLEEVE 1 2 HLCP2003500SL HLCP CYLINDER, SLEEVE 1
3 HLCP200CAP HLCP CYLINDER, CAP 1 3 HLCP200CAP HLCP CYLINDER, CAP 1
4 HLCP2001750RD HLCP CYLINDER, ROD 1 4 HLCP2003500RD HLCP CYLINDER, ROD 1
5 HLCP200PSTN HLCP CYLINDER, PISTON 1 5 HLCP200PSTN HLCP CYLINDER, PISTON 1
6 HLCP200PSTNBU HLCP CYLINDER, PISTON BUSHING 1 6 HLCP200PSTNBU HLCP CYLINDER, PISTON BUSHING 1
7 HLCP200SEGM HLCP CYLINDER, SEGMENT KIT 1 7 HLCP200SEGM HLCP CYLINDER, SEGMENT KIT 1
8 BHS006Y BALLUF INDUCTIVE SENSOR M5X0,5 NPN 2 8 BHS006Y BALLUF INDUCTIVE SENSOR M5X0,5 NPN 2
9 HLCP200ASCREW1
HLCP CYLINDER, ASSEMBLY SCREWS.
M8x100 mm (Torque: 29.5 ft.lbs)
8 9 HLCP200ASCREW2
HLCP CYLINDER, ASSEMBLY SCREWS.
M8x140 mm (Torque: 29.5 ft.lbs)
8
10 HLCP200MSCREW
HLCP CYLINDER, MOUNTING SCREWS.
3/8-16 UNC x 1.75 inches (Torque: 52 ft.lbs)
10 10 HLCP200MSCREW
HLCP CYLINDER, MOUNTING SCREWS.
3/8-16 UNC x 1.75 inches (Torque: 52 ft.lbs)
10
11 HLCP200OILCAP HLCP CYLINDER, OIL CAPS 2 11 HLCP200OILCAP HLCP CYLINDER, OIL CAPS 2
12 HLCP200-SEALS HLCP CYLINDER, SEAL KIT 1 12 HLCP200-SEALS HLCP CYLINDER, SEAL KIT 1
12a WE3100320-T46V EXCLUDER 1 12a WE3100320-T46V EXCLUDER 1
12b RSK100320-T46V STEPSEAL 1 12b RSK100320-T46V STEPSEAL 1
12c PT0200560-T46V GLYD RING 1 12c PT0200560-T46V PT0100360-T46V 1
12d S35P16X22.1X4.7 INNER PISTON O-RING 1 12d S35P16X22.1X4.7 INNER PISTON O-RING 1
12e OR3007000-VC009 SLEEVE O-RING 2 12e OR3007000-VC009 SLEEVE O-RING 2
13 HLCP200SPACER HLCP CYLINDER, SPACER PLATE 1 13 HLCP200SPACER HLCP CYLINDER, SPACER PLATE 1
14a HLCP200BSEBU BODY SENSOR BUSHING 27MM, WITH NUT 1 14a HLCP200BSEBU BODY SENSOR BUSHING 27MM, WITH NUT 1
14b HLCP200CSEBU CAP SENSOR BUSHING 27MM, WITH NUT 1 14b HLCP200CSEBU CAP SENSOR BUSHING 27MM, WITH NUT 1
TABLE 4.4: HLCP150-1375 TABLE 4.5: HLCP150-2750
ITEM NO. PART NO. DESCRIPTION QTY. ITEM NO. PART NO. DESCRIPTION QTY.
1 HLCP150BODY HLCP CYLINDER, BODY 1 1 HLCP150BODY HLCP CYLINDER, BODY 1
2 HLCP1501375SL HLCP CYLINDER, SLEEVE 1 2 HLCP1502750SL HLCP CYLINDER, SLEEVE 1
3 HLCP150CAP HLCP CYLINDER, CAP 1 3 HLCP150CAP HLCP CYLINDER, CAP 1
4 HLCP1501375RD HLCP CYLINDER, ROD 1 4 HLCP1502750RD HLCP CYLINDER, ROD 1
5 HLCP150PSTN HLCP CYLINDER, PISTON 1 5 HLCP150PSTN HLCP CYLINDER, PISTON 1
6 HLCP150PSTNBU HLCP CYLINDER, PISTON BUSHING 1 6 HLCP150PSTNBU HLCP CYLINDER, PISTON BUSHING 1
7 HLCP150SEGM HLCP CYLINDER, SEGMENT KIT 1 7 HLCP150SEGM HLCP CYLINDER, SEGMENT KIT 1
8 BHS006Y BALLUF INDUCTIVE SENSOR M5X0,5 NPN 2 8 BHS006Y BALLUF INDUCTIVE SENSOR M5X0,5 NPN 2
9 HLCP150ASCREW1
HLCP CYLINDER, ASSEMBLY SCREWS.
M6x80 mm (Torque: 12.6 ft.lbs)
8 9 HLCP150ASCREW2
HLCP CYLINDER, ASSEMBLY SCREWS.
M6x110 mm (Torque: 12.6 ft.lbs)
8
10 HLCP150MSCREW
HLCP CYLINDER, MOUNTING SCREWS.
5/16-18 UNC x 1.50 inches (Torque: 27 ft.lbs)
10 10 HLCP150MSCREW
HLCP CYLINDER, MOUNTING SCREWS.
5/16-18 UNC x 1.50 inches (Torque: 27 ft.lbs)
10
11 HLCP150OILCAP HLCP CYLINDER, OIL CAPS 2 11 HLCP150OILCAP HLCP CYLINDER, OIL CAPS 2
12 HLCP150-SEALS HLCP CYLINDER, SEAL KIT 1 12 HLCP150-SEALS HLCP CYLINDER, SEAL KIT 1
12a WE3100250-T46V EXCLUDER 1 12a WE3100250-T46V EXCLUDER 1
12b RSK100250-T46V STEPSEAL 1 12b RSK100250-T46V STEPSEAL 1
12c PT0200450-T46V GLYD RING 1 12c PT0200450-T46V PT0100360-T46V 1
12d S35P13X17.5X3.6 INNER PISTON O-RING 1 12d S35P13X17.5X3.6 INNER PISTON O-RING 1
12e OR2505500-VC009 SLEEVE O-RING 2 12e OR2505500-VC009 SLEEVE O-RING 2
13 HLCP150SPACER HLCP CYLINDER, SPACER PLATE 1 13 HLCP150SPACER HLCP CYLINDER, SPACER PLATE 1
14a HLCP150BSEBU BODY SENSOR BUSHING 27MM, WITH NUT 1 14a HLCP150BSEBU BODY SENSOR BUSHING 27MM, WITH NUT 1
14b HLCP150CSEBU CAP SENSOR BUSHING 27MM, WITH NUT 1 14b HLCP150CSEBU CAP SENSOR BUSHING 27MM, WITH NUT 1
