User’s Guide ______________________________________________________________________
36 __________________________________________________________________ M210906EN-C
0803-031
Figure 13
Mounting WXT520 to Pole Mast Using Optional
Mounting Kit
The following numbers refer to
:
1
=
Mounting kit
2
=
Fixing screw
NOTE
When removing WXT520 from the pole just turn the transmitter so
that it snaps out from the mounting kit. When replacing the device the
alignment is not needed.
