AIMB-210 User Manual

Appendix B

I/O Pin

ssignments

B.11

HDD LED and External Speaker Connector

(JFP2/HDD LED and SPEAKER)

The single board computer has its own buzzer. You can also connect it to the external
speaker on your computer chassis.

B.12

ATX Soft Power Switch and Reset Connector

(JFP1/ PWR-SW and RESET)

Table B.11: External Speaker Connector (JFP2/SPEAKER)

Pin Signal

1 SPK+

2 HDDLED+

3 NC

4 HDDLED-

5 SPK_IN

6 SMB_DAATA

7 SPK-

8 SMB_CLK

Table B.12: Reset Connector (JFP1/ RESET)

Pin Signal

1 PWR_BTN#
2 GND
3 RESET
4 GND
