AIMB-210 User Manual 36
3.1 Introduction
Advantech provides a full-featured Award BIOS 6.0 that delivers superior perfor-
mance, compatibility and functionality for manufactures of Industrial PCs and
embedded boards; its many options and extensions let you customize your
products to a wide range of designs and target markets.
The modular, adaptable AwardBIOS 6.0 supports the broadest range of third-
party peripherals and all popular chipsets, plus Intel
®
, AMD, nVidia, VIA, and
compatible CPUs from 386 through Pentium ® and AMD Geode™, K7 and K8
(including multiple processor platforms), and VIA Eden C3 and C7 CPU.
You can use Advantech’s utilities to select and install features to suit your
design needs.
3.2 BIOS Setup
The AIMB-210 Series system has build-in AwardBIOS with a CMOS SETUP
utility which allows users to configure required settings or to activate certain sys-
tem features.
The CMOS SETUP saves the configuration in the CMOS RAM of the mother-
board. When the power is turned off, the battery on the board supplies the nec-
essary power to the CMOS RAM.
When the power is turned on, press the button during the BIOS POST
(Power-On Self Test) will take you to the CMOS SETUP screen.
Control Keys
< ↑ >< ↓ >< ← >< → > Move to select item
Select Item
Main Menu - Quit and not save changes into CMOS
Sub Menu - Exit current page and return to Main Menu
Increase the numeric value or make changes
Decrease the numeric value or make changes
General help, for Setup Sub Menu
Item Help
Load Previous Values
Load Setup Default
Save all CMOS changes
