71
AIMB-210 User Manual
Appendix B
I/O Pin
A
ssignments
B.3
VGA Connector (VGA1)
B.4
RS-232 Interface
Table B.3: VGA Connector (VGA1)
Pin
Signal
Pin
Signal
1
RED
9
CRT_VCCIN
2
VGA_G
10
GND
3
VGA_B
11
N/C
4
N/C
12
V_SDAT
5
GND
13
H-SYNC
6
GND
14
V-SYNC
7
GND
15
V_SCLK
5
15
1
11
10
6
Table B.4: RS-232 Interface (COM1~COM4)
Pin
Signal
1
DCD
2
DSR
3
RXD
4
RTS
5
TXD
6
CTS
7
DTR
8
RRI
9
GND
1
9
2
8
