1.3.6 Industrial features
! Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels)
! TPM1.2(optional): Infineon TPM chip SLB9635 TT 1.2 Module Onboard
1.3.7 Mechanical and environmental specifications
! Operating temperature: 0 ~ 60° C (32 ~ 140° F, Depending on CPU)
! Storage temperature: -20 ~ 70° C (-4 ~ 158° F)
! Humidity: 5 ~ 95% non-condensing
! Power supply voltage: +3.3 V, +5 V, +12 V, -12 V, 5 Vsb
! Power consumption:
+5 V @ 1.96 A, +3.3 V @ 1.21 A, +12 V @ 0.19 A, 5 VSB @ 0.28, -12 V@ 0.06
A. Measure the maximum current value which system under maximum load
(CPU: Top speed, RAM & Graphic: Full loading)
! Board size: 170 mm x 170 mm (6.69" x 6.69")
! Board weight: 0.365 kg
1.4 Jumpers and Connectors
Connectors on the AIMB-210 motherboard link it to external devices such as hard
disk drives and a keyboard. In addition, the board has a number of jumpers used to
configure your system for your application.
The tables below list the function of each of the board jumpers and connectors. Later
sections in this chapter give instructions on setting jumpers. Chapter 2 gives instruc-
tions for connecting external devices to your motherboard.
Table 1.1: Jumpers
Label Function
CMOS1 CMOS clear
JPSON1 AT/ATX mode selector
JSETCOM2 Serial port: RS232/RS422/RS485
Table 1.2: Connectors
Label Functions
JFP1 Power Switch / Reset connector
JFP2 External speaker / SATA HDD LED connector / SM Bus connector
JFP3(Keyboard Lock
and Power LED)
Power LED
Suspend: Fast flash (ATX/ AT)
System On: ON (ATX/ AT)
System Off: OFF (AT)
System Off: Slow flash (ATX)
CMOS1 CMOS clear (Default 1-2)
JSETCOM2 COM2 RS232/422/485 Jumper Setting
JLV1 LVDS1 LCD power 3.3V/5V selection Default (1-2, 3.3V)
JLV2 LVDS2 LCD power 3.3V/5V selection Default (1-2, 3.3V)
JPSON1 AT(1-2) / ATX(2-3) (Default 2-3)
LPT1 parallel connector
