3 AIMB-210 User Manual
Chapter 1
G
eneral
Information
1.3 Specifications
1.3.1 System
! CPU: Intel
®
Atom ™ N270 1.6 GHz FSB 533 MHz
! BIOS: Award SPI 16 Mbit BIOS
! System chipset: Intel ® 945GSE with ICH7M
! SATA hard disk drive interface: Two on-board SATA connectors with data
transmission rate up to 150 MB
! IDE Interface: One onboard IDE connector supporting up to two enhanced IDE
devices. Supports PIO mode 4 (16.67 MB/s data transfer rate) and ATA 33/66/
100 (33/66/100 MB/s data transfer rate) BIOS enabled/disabled
! CF interface: Supports compact flash Type II
1.3.2 Memory
! RAM: Up to 2 GB in 1 slots 200-pin SODIMM sockets. Supports single channel
DDRII 533 SDRAM
1.3.3 Input/Output
! PCI bus: 1 PCI slot
! Enhanced parallel port: Configured to LPT1, with 25 pin box header. Supports
EPP/SPP/ECP
! Serial ports: Six serial ports, COM2 is RS-232/422/485 and five of RS-232
serial ports
! Keyboard and PS/2 mouse connector: Two 6-pin mini-DIN connectors are
located on the mounting bracket for easy connection to a PS/2 keyboard and
mouse
! USB port: Supports up to eight USB 2.0 ports with transmission rate up to 480
Mbps, 4 on board pin header and 4 external ports)
! GPIO connector: 16-bit general purpose Input/Output
1.3.4 Graphics
! Controller: Chipset integrated VGA controller
! Display memory: Dynamically shared system memory up to 224 MB
! CRT: Up to 2048 x 1536 resolution, 400 MHz RAMDAC
! LVDS1: Supports single channel 18-bit/ dual channel 36-bit LVDS
! LVDS2 (optional): Supports single channel 18/24-bit/ dual channel 24/48-bit
LVDS via Chrontel 7308B transmitter
! TV-Out: Support both S-video and composite video via cables (TV-out function
is not supported during POST stage)
1.3.5 Ethernet LAN
! Supporting dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus
which provides 500 MB/s data transmission rate
! Controller: LAN: Realtek RTL8111C
