2. Carefully insert the data logger (Serial or USB) into the connector

slot, making sure to push the data logger firmly into place.

Inserting the Serial or USB data logger into the Envoy8X

3. Rejoin the case halves, making sure the data logger cable passes

through the cable channel.

4. Fasten using the three screws you removed in step 1.

Data Logger

Cable Channel

Serial

Data Logger

Data Logger

Cable Channel

USB

Data Logger
