Page 6

4
Preparing the Envoy8X
• Install the data logger
• Install the batteries and AC power source
• Mount your Envoy8X
Install the Data Logger
Installing the data logger (supplied with WeatherLink) is the first
step in preparing the Envoy8X to transmit data to the software.
CAUTION: Plugging or unplugging the data logger while power is applied to the
Envoy8X can lock up or damage the logger. The WeatherLink data
logger must be installed before you install the batteries or plug in the
AC power adapter.
1. Remove the three screws from the back of the Envoy case, and
separate the case halves to expose the data logger connector.
Env
oy8
X
R
