9
For better reception over greater distances or for weaker signals,
consider using a Wireless Repeater (#7626 or 7627) or Long-Range
Repeaters (#7653 or 7654) to strengthen the signal or increase the
distance between your transmitters and Envoy8X.
Wall Mounting the Envoy8X
1. Use the provided wall mounting template on the next page as an
example of hole spacing and alignment when installing your
Envoy8X.
2. Use the template as a guideline for the hole markings on the wall
where you want to mount the Envoy8X, and use a pencil to mark
the location for the two mounting screws.
The screws should be 3.25
'' (82.5
mm) apart and lined up verti-
cally.
3. Drill the marked locations with a
3/32 '' or 7/64 '' (2.2 to 2.7 mm)
drill bit.
4. Drive the two #6 x 1 '' (3.5 mm x
25 mm) pan head self-threading
screws into the wall.
5. Leave at least a 1/8 '' (3 mm)
space between the wall and the
heads of the screws.
3.25"
(82.55mm)
Drill 3/32"
or 7/64"
(~2.2 to 2.7mm)
Holes
