PC CONNECTION
The meter can interface with a personal computer to
capture on-line or stored data.
Connection procedures:
1. Plug a USB or RS232 cable into the jack labeled RS232
on the rear side of the meter.
2. Plug the D-sub 9 pin type connector into a computer
Serial COM port. COM ports 1-8 can be used.
3. Insert the CD-Rom into the computer and follow the
procedure in the operation manual located on the CD.
Protocol information
RS232 protocol settings: 9600 bps, 8 data bits, no parity.
(Transmits ASCII code every second.)
Normal Data:
pxx.xxpH: mxx.xxmV: Cxxxx(xx.xx, xxx.x)mS(uS) : Dxxxx
(xx.xx, xxx.x)ppm(ppt) : Sxx.xxppt:Txxx.xC(F):Txxx.xC(F)
@ 2007-04-18
18:48:48LRCCRLF
Protocol Information
Errors:
ExxNul: ExxNul: ExxNul: ExxNul: ExxNul: ExxNull: ExxNul
@ 2007-04-18
18:48:48LRCCRLF
Description:
$pH:mV:Cond:TDS:Salt:TpH:Tcon LRC CRLF
