Ag Leader SMS Mobile Icons/Buttons Quick Start Guide User Manual

Page 9

SMS Mobile Buttons
Revision 8/1/2013 © 2013 Ag Leader Technology, Inc All Rights Reserved

Icon

Name

Description

Field Operations

Enable Virtual

Implement Switch

Allows you to disable the VIS functionality if you want to log

coverage without any automated on/off logging and swath
width adjustment.

Snap

When snap is enabled, the addition of new spatial data will snap

to the closest point on the closest object if you are within a
certain distance of that object. This is useful for adding to
existing objects, such as adding laterals to a tile line or adding a
polygon region that joins another region.

All

Undo

Select to undo the last function that was completed.

All

Redo

Select to redo the last function that was undone.

Cut Selection

Select to remove the currently selected object from the map.

The object is then available to paste.

Copy Selection

Select to make a copy of the current selection that can then be

pasted as a new object.

Copy from Layer

Select to make a copy of either the current field boundary or a

currently mapped layer. If a mapped layer is selected then all
objects in the layer will be copied.

Paste

Select to paste an object(s) that has been cut or copied.

Delete Selection

Select to delete the current selected object(s).

Merge Selection

Merges multiple objects that have been selected. Useful if you
have divided a polygon into multiple polygons and you wish to
merge them together into one polygon.

Delete All

Deletes all objects that are on the current layer.

All

Move

Allows you to move a select object(s) by dragging the stylus on
the map.

All
