SMS Mobile Buttons
Revision 8/1/2013 © 2013 Ag Leader Technology, Inc All Rights Reserved
9
Icon Name Description Field Operations
Move to Current
Allows you to move a point object to the current position. This is
useful to adjust the position of a point to the true/current GPS
position automatically vs having to manually move it.
All
Divide by Line
Allows you to divide a polygon or line by dragging a line across
the object(s) on the map. The divide line must completely cross
an object to divide it.
Divide by Polygon
Allows you to divide a polygon or line by driving or drawing a
region on the map. The divide polygon must be manually defined
by adding its vertices one at a time.
Auto-Fill Values
Select this to tool to fill values in for a selected attribute for
either all objects in dataset or only selected objects.
Edit Attributes
Allows you to edit the attribute values that are editable for a
selected object(s).
All
Edit Properties
Allows you to edit the property values that are editable for the
current dataset.
All
Edit Landmark Notes
Allows you to edit the Landmark Notes you have in SMS Mobile.
All Landmark Notes in a Mobile Project will be editable. You can
edit or delete Landmark Notes.
All
Edit Layer/Picture Notes
Allows you to edit the Layer/Picture Notes you have in SMS
Mobile. Only the Layer/Picture Notes for the current edit layer
will be available to edit. You can edit or delete these notes.
All
Selection Mode -
Intersection
Selection mode that only selects areas of an object that are
intersected by your drawn selection area and not the whole
object. This can be used to query sub-regions of an object or
even edit an object.
Selection Mode - Whole Default selection mode that selects whole objects.
Selection Mode - Vertices
Selection mode that allows you to select the vertices that make
up polygons and lines. Individual vertices can be moved or
deleted but they can’t be added.
Point Select
Allows the selection of an object by just selecting a point on
the object. There is no multi-point selection though.
Rectangle Select
Allows the selection of an object(s) by drawing a
rectangular region.
