PF3000 and PF3000 Pro Using PF with HarvestMaster
Ag Leader Technology Setup
September 2000 5
Example:
Known Angle: 30 degrees
Tilt sensor reading: 33 degrees
Current Tilt Sensor Multiplier: 67 degrees
30
33
= 0.909
0.909 x 67 = 61
Final Tilt Sensor Multiplier Setting is 61.
Tilt Sensor Offset: This should be set to 0 if you do not have a tilt sensor.
If using a tilt sensor, and it cannot be adjusted to read “0” when the
conveyor is horizontal, set Tilt Sensor Offset according to the following:
a. With tilt sensor adjusted to its final adjustment and with conveyor
perfectly level, view "Tilt" reading under the HarvestMaster Sensor
Diagnostic Screen.
b. Enter the "Tilt" reading as the setting for "Tilt Sensor Offset", but
enter the opposite sign of the “Tilt” value. Example: If “Tilt” value is
2, enter –2 for “Tilt Sensor Offset”. If “Tilt” value is –2, enter 2 for
“Tilt Sensor Offset”.
Flow Cutoff: This is the minimum flow rate for recording data. Initially,
this is usually set to zero.
Profile Height Multiplier: Set to - 3.34 inches. If using metric units set
to - 8.48 cm.
Profile Threshold: Set to 0 inches. If using metric units set to 0 cm.
Number of Profile Sensors: Set to 5.
