PF3000 and PF3000 Pro Using PF with HarvestMaster
Ag Leader Technology Setup
September 2000 3
Before Setup These instructions only cover information about interfacing with the
HarvestMaster HM500 or HM570 yield monitor. Information not found in these
instructions regarding the use of the PF3000 or PF3000 Pro can be found in the
Operators Manual.
Ensure your PF3000 or PF3000 Pro has the HarvestMaster firmware version
installed. Verify by checking the screen after turning on the monitor. It will
display "HarvestMaster Version X.XX"
NOTE: You may download the latest firmware version from our web site
at www.agleader.com.
NOTE: If you install the HarvestMaster firmware version over a non-
HarvestMaster firmware version and you want to save the data from the
previous version, copy the data to the card before installing. After
installing the HarvestMaster version you will have to Newbox to get the
monitor to start. To Newbox, turn on the PF and when “Checking”
appears, press and hold down the bottom right arrow key. Press the
NEWBOX key when the monitor displays it.
To edit a setting in a setup screen, use the UP or DOWN ARROW keys to
highlight the item. Press the EDIT key and use the UP or DOWN or LEFT or
RIGHT ARROW keys to change the setting. Press ACCEPT key to make the
changed setting final.
Setup – Step 1
Metric or Imperial
Units
To view this screen, press the SETUP key and CONSOLE key.
Set Units of Measure to “Imperial” or “Metric”. This setting puts the PF in the
correct units’ mode.
Setup – Step 2
HarvMast Sensor
Setup Screen
To view this screen press the SETUP key and HARVMAST SENSOR key.
The following shows which settings are changeable based on “Yield Sensor
Type”.
Yield Sensor Type = Load Cell
Load Cell A Multiplier
Load Cell B Multiplier
Load Cell A Offset
Load Cell B Offset
Tilt Sensor Multiplier
Tilt Sensor Offset
Flow Cutoff
Yield Multiplier Yield Sensor Type = Profile
Flow Cutoff
Profile Height Multiplier
Profile Threshold
Number of Profile Sensors
Yield Multiplier
