Using PF with HarvestMaster

PF3000 and PF3000 Pro

Calibration

Ag Leader Technology

September 2000

10

Calibration – Step 1

Tare Calibration
Screen

To view this screen, press the CAL key and TARE key.

Press the PERFORM TARE key to start the tare. Make sure the conveyor is
running empty when you press PERFORM TARE.

The tare value gets averaged over the belt length, thus the tare will take several
seconds (one complete belt revolution) to complete. The tare is complete when
“Tare Complete” gets to 100%.

In many operations, you might initiate a tare operation only once per day, or
even once every few days. In muddy operations, it is advisable to tare the
system right after completing a load.

Calibration – Step 2

Weight Calibration
Screen

To view this screen, press the CAL key and WEIGHT key. Refer to the steps
below:

Note: It is recommended to obtain the actual weight of three or four loads for
each crop harvested. Also, it is recommended that you tare the conveyor before
harvesting each load being used for calibration.

a) Use the Up or Down Arrow keys to select the crop.
b) Press ENTER WEIGHT key to add actual weights.

1) Use the Up or Down Arrow keys to set field.
2) Press key to right of Load and use Up or Down Arrow keys to set load.
3) Press key to right of “Act. Weight” and use Up or Down Arrow keys to

set actual weight.

4) Repeat steps 1-3 and enter all actual weights. Press EXIT key when

finished.

c) Press SHOW CAL LOADS key.
d) Press PERFORM CAL key. View the maximum and average error and

press the EXIT key.

e) If errors of any loads are too high you can uncheck the load by pressing the

CAL ON/OFF key. Press PERFORM CAL key again if you uncheck any
loads.

Note: When you calibrate weight for a crop, all the data that was previously
recorded and will be recorded (including logged data) for the crop will be
adjusted to the same calibration.
