GE PGP990SENSS - Manual (Page 29)

,QVWDOODWLRQ,QVWUXFWLRQV
),1$/$66(0%/<
$66(0%/(7+(&22.723
Install the sealed burner module, caps and grate
on the right side of the unit. See page 10 for
correct installation.
Install the optional sealed burner module or the
grill/griddle burner on the left side of the unit.
If the grill/griddle burner was installed, place the
grill grate or griddle cover over it as desired.
127( The grill and griddle can be installed on the
left side only.
&KHFNIRUSURSHULJQLWLRQ
Push in one control knob and turn to /,7( position.
The igniter will spark and the burner will light;
igniter will cease sparking when the burner is lit.
First test may require some time while air is
flushed out of the gas line.
Turn knob to 2))
Repeat the procedure for each burner.
Adjust the air shutters (see LP Conversion
Instructions).
Adjust the low flame setting (see LP Conversion
Instructions).
17 ,167$//*5($6(-$5'2:1'5$)7
),/7(5$1'9(17*5,//(
Screw the grease jar into the grease jar holder on
the bottom of the cooktop.
'RQRWRSHUDWHWKHYHQWZLWKRXWWKHILOWHULQSODFH
Place the filter through the vent opening.
Make sure it rests, at an angle, on the supports in
the vent opening. Latch it in place.
Place the vent grille onto the downdraft opening so
that the open part of the grille is toward the rear of
the unit.
&+(&.23(5$7,212)'2:1'5$)7
Turn the vent fan speed control to HI, MED and LO
to make sure all speeds operate correctly.
18
29
or
Grille
