Table 6 HP All-in-One SB600c Server Blade LEDs

Item

Description

Status

1

Hard drive bay 1

N/A

2

Power On/Standby button

N/A

3

Local I/O connector*

N/A

4

Hard drive bay 2

N/A

5

Server blade handle

N/A

6

Release button

N/A

7

NIC 2 LED*

Green = Network linked
Green flashing = Network activity
Off = No link or activity

8

NIC 1 LED*

Green = Network linked
Green flashing = Network activity
Off = No link or activity

9

Health LED

Green = Normal
Flashing = Booting
Amber = Degraded condition
Red= Critical condition

10

UID LED

Blue = Identified
Blue flashing = Active remote management

11

Serial pull tab

N/A

44

All-in-One SB600c Storage Blade Solution components
