HP AiO SB600c Server and Storage Blades
SB600c server and storage blades support each other in partner bays. Each partner bay will hold one
server blade and one storage blade.
• If the storage blade is installed in an odd-numbered bay, install the partner server blade in
the adjacent even-numbered bay to the right.
• If the storage blade is installed in an even-numbered bay, install the partner server blade in
the adjacent odd-numbered bay to the left.
Installing the HP AiO SB600c Server and Storage Blades
IMPORTANT:
Install the storage blade prior to installing the server blade.
CAUTION:
To prevent improper cooling and thermal damage, do not operate the server blade or the enclosure
unless all hard drive and device bays are populated with either a component or a blank.
1. Remove the blank.
2. Remove the enclosure connector cover.
All-in-One SB600c Storage Blade Solution 13
