Page 38: Array configuration utility
WARNING!
During a recovery process, this DVD overwrites the original OS logical drives. All data on these
drives will be erased.
Two methods are available for system recovery:
•
iLO virtual DVD-ROM
•
USB DVD-ROM
NOTE:
Using iLO 2 virtual DVD-ROM to restore your system will take longer than the USB DVD-ROM method.
iLO 2 virtual DVD-ROM
This method uses iLO 2 virtual System Recovery DVD to restore your original OS.
To restore with an iLO 2 virtual System Recovery DVD:
1.
Insert the System Restore DVD into the client PC that is using the iLO 2 Remote Console.
2.
Remotely access the server blade through iLO 2.
3.
Click the Virtual Devices tab.
4.
Select Virtual Media.
5.
Use the Virtual Media applet to select the local DVD or image file and connect the Virtual DVD to
the server blade.
6.
Use the iLO 2 Virtual Power Button feature to reboot the server blade.
7.
Follow the quick restore instructions
USB DVD-ROM
This method uses System Recovery DVD to restore your original OS.
To restore with the System Recovery DVD:
1.
Use the local I/O cable to connect a USB DVD-ROM drive to the server blade.
See
Accessing a server blade with local media devices
2.
Insert the System Recovery DVD into the USB DVD-ROM drive.
3.
Reboot the server blade.
4.
After the server blade boots, follow the quick restore instructions.
Configuration tools
Array Configuration Utility
NOTE:
ACU does not support mixing SAS and SATA drives in the same logical volume.
ACU is a browser-based utility with the following features:
•
Runs as a local application or remote service
38
Configuration utilities
