• Install Type II mezzanine cards only on mezzanine 2 connector.
To install the component:
1. Power down the server blade.
See 19 for more information.
2. Remove the server blade.
See
Removing the HP AiO SB600c Server Blade on page 20 for more information.
3. Remove the access panel. See Removing the access panel on page 21 for more information.
4. Remove the mezzanine connector cover.
Figure 6 Removing the mezzanine connector cover
5. Install the mezzanine card. Press down on the connector to seat the board.
Figure 7 Installing the mezzanine card.
6. Install the access panel. See Installing the access panel on page 22
32 Hardware Options installation and cabling
