7. Install the server blade. See Installing the HP AiO SB600c Server and Storage Blades on page 13
Cabling
In this section
• Using the local I/O cable
• Connecting locally to a server blade with video and USB devices
Using the local I/O cable
The local I/O cable enables the user to perform server blade administration, configuration, and
diagnostic procedures by connecting video and USB devices directly to the server blade.
Connecting locally to a server blade with video and USB devices
Use the local I/O cable to connect a monitor and any of the following USB devices:
• USB hub
• USB keyboard
• USB mouse
• USB DVD-ROM drive
• USB diskette drive
Multiple configurations are possible. This section offers two possible configurations.
Accessing a server blade with local KVM
CAUTION:
Before disconnecting the local I/O cable from the connector, always squeeze the release buttons on the
sides of the connector. Failure to do so can result in damage to the equipment.
NOTE:
For this configuration, a USB hub is not necessary. To connect additional devices, use a USB hub.
1. Connect the local I/O cable to the server blade.
2. Connect the video connector to a monitor.
3. Connect a USB mouse to one USB connector.
4. Connect a USB keyboard to the second USB connector.
