Chapter 5 Installing Additional Memory
44
a. Lower the panel into place. A slotted flange extends from the top of
the panel on either side. Lower the slots over the matching tabs on the
satellite chassis
b. Tighten the captive screws.
6. Reattach the lower fan module:
a. On each side of the back of the fan module are two slots. Line these
slots up with the flanges on the fan’s mounting rails.
b. Push the fan module onto the mounting rails until it clicks into place.
7. Slide the satellite chassis into the base chassis.
8. Power up the NetServer. See Chapter 2 for details.
